K Digital Controller Write Protocol Appendix G
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Level 0 Parameters (Sequence No. 065 (Hex 0041))
Writes parameters (set points) in level 0 to multiple units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units × 2 + 2
+1 Number of units (4 digits Hex) 0001 to 0008
+2 1st unit
Unit No. (2 digits BCD)
00 to 31
+3 1st unit
Set point (4 digits BCD)
Set point lower limit to upper limit
•
•
•
+17
(max.)
8th unit
Set point (4 digits BCD)
Set point lower limit to upper limit
(Undefined) Unit No.
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+16
+17
(Undefined) Unit No.
Number of units
(Undefined) Unit No.
~ ~
Set point
Set point
Set point
1st unit
2nd unit
8th unit (max.)
