Appendix H
E5ZE Temperature Controller Read Protocol
The E5ZE Temperature Controller Read Protocol reads and controls various parameters in remote mode for
the Temperature Controller connected to the Serial Communications Unit/Board via RS-232C or RS-422/485
cable.
Note All sequences in this appendix operate on memory bank 0 and cannot be used for other memory banks.
Structure of the Protocol
The following table shows the structure of the E5ZE Temperature Controller Read Protocol
Note 1. The hexadecimal equivalents of sequences numbers are given in parentheses.
2. Ladder Interface Settings
YES: User settings are required for the 3rd or 4th operands of PMCR.
Sequence
No.
Communications sequence
name
Function Ladder interface
Send word
allocation
Receive word
allocation
100 (0064) Read set point Reads the set points. Yes Yes
101 (0065) Read process value Reads the process values. Yes Yes
102 (0066) Read output value Reads the output values. Yes Yes
103 (0067) Read set point, process value, and
output value
Reads the set points, process val-
ues, and output values.
Ye s Ye s
104 (0068) Read proportional band, integral
time, and derivative time
Reads the proportional bands,
integral times, and derivative
times.
Ye s Ye s
105 (0069) Read control period Reads the control periods. Yes Yes
106 (006A) Read output mode Reads the output modes. Yes Yes
107 (006B) Read alarm mode Reads the alarm modes. Yes Yes
108 (006C) Read alarm temperature Reads the alarm temperatures. Yes Yes
109 (006D) Read hysteresis Reads the hysteresis. Yes Yes
110 (006E) Read operation status Reads the operation status. Yes Yes
111 (006F) Read error status Reads the error status. Yes Yes
112 (0070) Read setting unit Reads the setting units. Yes Yes
113 (0071) Read input shift value Reads the input shift values. Yes Yes
114 (0072) Read manual reset value Reads the manual reset values. Yes Yes
115 (0073) Read ramp value Reads the ramp values. Yes Yes
116 (0074) Read present set point Reads the present set points. Yes Yes
117 (0075) Read output value limits Reads the output value limits. Yes Yes
118 (0076) Read output value change rate
limit
Reads the output value change
rate limits.
Ye s Ye s
119 (0077) Read HB alarm and HS alarm
valid channels
Reads the HB alarm and HS alarm
valid channels.
Ye s Ye s
120 (0078) Read heater burnout/SSR failure
detection currents
Reads the heater burnout/SSR
failure detection currents.
Ye s Ye s
121 (0079) Read heater current and SSR
leakage current
Reads the heater currents and
SSR leakage currents.
Ye s Ye s
122 (007A) Read dead band/overlap band Reads the dead bands and over-
lap bands.
Ye s Ye s
123 (007B) Read cooling coefficient Reads the cooling coefficients. Yes Yes
