E5
@
J Temperature Controller Protocol Appendix J
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Parameters 2 (Sequence No. 206 (Hex 00CE))
Writes the proportional bands, integral times, and derivative times to multiple units.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units × 5 + 2
+1 Number of units (4 digits Hex) 0001 to 0019 (1 to 25 decimal)
+2 1st unit
Unit No. (2 digits BCD)
00 to 31
+3 1st unit
Set point (4 digits BCD)
0000 to 9999
+4 1st unit
Alarm value 1 (4 digits BCD)
0000 to 9999
+5 1st unit
Alarm value 2 (4 digits BCD)
0000 to 9999
+6 1st unit
Heater burnout alarm value 2
(4 digits BCD)
0000 to 9999
+7 2nd unit
Unit No. (2 digits BCD)
00 to 31
•
•
•
+126
(max.)
25th unit
Heater burnout alarm value 2
(4 digits BCD)
0000 to 9999
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+122
+123
+124
+125
(Undefined) Unit No.
Proportional band
~ ~
Integral time
Proportional band
Integral time
1st unit
31th unit (max.)
Derivative time
Derivative time
Number of units
(Undefined)
Unit No.
