592
ES100 @ Digital Controller Protocol Appendix K
Manual Mode (Sequence No. 274 (Hex 0112))
Switches the control mode to the manual mode.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Execute A.T. (Sequence No. 275 (Hex 0113))
Executes A.T.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units + 2
+1 Number of units (4 digits Hex) 0001 to 0020 (1 to 32 decimal)
+2 1st unit
Unit No. (2 digits BCD)
00 to 31
+3 2nd unit
Unit No. (2 digits BCD)
00 to 31
•
•
•
+33
(max.)
32nd unit
Unit No. (2 digits BCD)
00 to 31
(Undefined) Unit No.
First word of
send data
Number of send data words+0
+1
+2
+3
+33
(Undefined) Unit No.
Number of units
(Undefined) Unit No.
~ ~
32nd unit (max.)
2nd unit
1st unit
1st unit
First word of
send data
Number of send data words+0
+1
+2
+3
+64
+65
(Undefined) Unit No.
Number of units
PID set No.
~ ~
(Undefined) Unit No.
32nd unit (max.)
PID set No.
