ES100 @ Digital Controller Protocol Appendix K
Change Pattern No. (Sequence No. 277 (Hex 0115))
Changes the pattern number.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Change Bank No. (Sequence No. 278 (Hex 0116))
Changes the bank number.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
Number of units × 2 + 2
+1 Number of units (4 digits Hex) 0001 to 0020 (1 to 32 decimal)
+2 1st unit
Unit No. (2 digits BCD)
00 to 31
+3 1st unit
Pattern No. (4 digits BCD)
0001 to 0063
+4 2nd unit
Unit No. (2 digits BCD)
00 to 31
•
•
•
+64 32nd unit
Unit No. (2 digits BCD)
00 to 31
+65
(max.)
32nd unit
Pattern No. (4 digits BCD)
0001 to 0063
1st unit
First word of
send data
Number of send data words
+0
+1
+2
+3
+64
+65
(Undefined) Unit No.
Number of units
Pattern No.
~ ~
(Undefined) Unit No.
32nd unit (max.)
Pattern No.
1st unit
First word of
send data
Number of send data words+0
+1
+2
+3
+64
+65
(Undefined) Unit No.
Number of units
Bank No.
~ ~
(Undefined) Unit No.
32nd unit (max.)
Bank No.
