ES100 @ Digital Controller Protocol Appendix K
General-purpose Command (Sequence No. 280 (Hex 0118))
Sends the specified data and stores the received data in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
Number of units × 5 + 1
+1 1st unit
Operation status (2 digits BCD)
Hold (2 digits BCD)
00: Reset
01: Run
00: Not hold
01: Hold
+2 1st unit
Auto/manual (2 digits BCD)
SP mode (2 digits BCD)
00: Auto mode
01: Manual mode
00: Local SP mode
01: Remote SP mode
02: Fixed SP mode
+3 1st unit
Setting mode (2 digits BCD)
Valid pattern No. (2 digits BCD)
00: Local setting mode
01: Remote setting mode
02: External setting mode
00 to 63
+4 1st unit
A.T. (2 digits BCD)
Valid PID set No. (2 digits hex)
00: Not A.T.
01: A.T.
01 to 08
+5 1st unit
Wait (2 digits BCD)
Operation mode (2 digits BCD)
00: Not waiting
01: Waiting
02: Wait alarm output
00: Setting level 1 (without technical mode)
01: Setting level 1 (with technical mode)
02: Setting level 2 (without technical mode)
03: Setting level 2 (with technical mode)
•
•
•
+125
(max.)
25th unit
Wait (2 digits BCD)
Operation mode (2 digits BCD)
00: Not waiting
01: Waiting
02: Wait alarm output
00: Setting level 1 (without technical mode)
01: Setting level 1 (with technical mode)
02: Setting level 2 (without technical mode)
03: Setting level 2 (with technical mode)
Send data
First word of
send data
Number of send data words
+0
+1
+2
+3
+249
Number of send data bytes
Send data (ASCII)
~ ~
(max. = 496 characters)
Send data (ASCII)
