Omron SYSMAC CV1000 User Manual

Appendix AStandard Models
110
Connectors and Cables
Name Specifications Model Maker
Multi-core cable UL approved UL2464 AWG28 x 5P IFS-RVV-SV Fujikura
UL approved UL2464-SB 5P x AWG28 Hitachi
Connector For Host Link Unit communications port 1
(25 pins)
XM2A-2501 OMRON
For Host Link Unit communications port 2
or host interface on CPU (9 pins)
XM2A-0901
Connector Hood For Host Link Unit communications port 1
(25 pins)
XM2S-2511 OMRON
For Host Link Unit communications port 2
or host interface on CPU (9 pins)
XM2S-0911
Optical Interface
Name Model Required number Remarks
Optical Module Z3RN-A-5 2 Connects RS-232C cable to optical fiber
cable.
Optical Fiber Cable
Z3F2-4SjM (see note)
1 PCF
AC Adapter Z3-GP01 2 (1) Two AC Adapters are required for port 2
and one AC adapter is required for port 1.
Note Cables with lengths of 1, 5, 10, 15, 20, 25, 30, 40, 50, 60, 70, 80, 90, 100, 110, 120, 130, 140, 150, 160, 170,
180, 190, 200, 250, 300, 350, 400, 450, and 500 m are available. When ordering, insert the required cable
length before the M in the model number (replacing the box: j).
Connecting Cable
RS-422 and RS-232C connecting cables are not sold by OMRON and must be provided by the user.
Plastic-clad Optical Fiber Cable
Link Adapters with the suffix -P in the model number can be extended up to 200 m by using plastic-clad opti-
cal fiber cable. Those without the suffix -P in the model number can be extended up to 800 m.
Cable type Description Operating environment Model
Indoor 0.1 m, with connector Operating temperature: –10
o
to 70
o
C 3G5A2-OF011
1 m, with connector 3G5A2-OF101
2 m, with connector 3G5A2-OF201
3 m, with connector 3G5A2-OF301
5 m, with connector 3G5A2-OF501
10 m, with connector 3G5A2-OF111
20 m, with connector 3G5A2-OF211
30 m, with connector 3G5A2-OF311
40 m, with connector 3G5A2-OF411
50 m, with connector 3G5A2-OF511
Indoor/outdoor 10 to 500 m, with connector
(order in increments of 1 m)
Operating temperature: –10
o
to 70
o
C 3G5A2-OF002
501 to 800 m, with connector
(order in increments of 1 m)
Operating temperature: 0
o
to 55
o
C
(Do not expose to direct sunlight)
Note Since optical fiber cable cannot be spliced as easily as ordinary cables when damaged or extended, be sure
to install an adequate length. The cable lengths above do not include connectors.
