5-1 C-mode Command List
The following tables lists all of the C-mode commands supported by Host Link
Unit. The CPU supports all the following commands except the I/O REGISTER
and the INITIALIZE commands. These two commands are not supported by the
host interface. The commands and command formats are the same for all other
C-mode commands regardless of whether the host interface or the Host Link
Unit is used.
Caution The node number assigned to a Host Link Unit on a Host Link System network is
called the “unit number” for the PC in the PC Setup and in the header portions of
command formats in the CV-series PC Operation Manual: Host Interface. When
coding commands for the Host Link Unit, be sure to use the node number and
not the unit number.
Header
Name PC mode Page
code RUN MONITOR DEBUG PROGRAM
RR CIO AREA READ Valid Valid Valid Valid 73
RL LINK AREA READ Valid Valid Valid Valid 73
RH HOLDING AREA READ Valid Valid Valid Valid 74
RC PV READ Valid Valid Valid Valid 74
RG TC STATUS READ Valid Valid Valid Valid 75
RD DM AREA READ Valid Valid Valid Valid 75
RJ AUXILIARY AREA READ Valid Valid Valid Valid 76
CR DM AREA READ (FIXED) Valid Valid Valid Valid 76
WR CIO AREA WRITE Not valid Valid Valid Valid 77
WL LINK AREA WRITE Not valid Valid Valid Valid 77
WH HOLDING AREA WRITE Not valid Valid Valid Valid 78
WC PV WRITE Not valid Valid Valid Valid 78
WD DM AREA WRITE Not valid Valid Valid Valid 79
WJ AUXILIARY AREA WRITE Not valid Valid Valid Valid 79
R# SV READ 1 Valid Valid Valid Valid 80
R$ SV READ 2 Valid Valid Valid Valid 81
R% SV READ 3 Valid Valid Valid Valid 83
W# SV CHANGE 1 Not valid Valid Valid Valid 84
W$ SV CHANGE 2 Not valid Valid Valid Valid 85
W% SV CHANGE 3 Not valid Valid Valid Valid 87
MS STATUS READ Valid Valid Valid Valid 89
SC STATUS WRITE Valid Valid Valid Valid 90
MF ERROR READ Valid Valid Valid Valid 91
KS FORCED SET Not valid Valid Valid Valid 92
KR FORCED RESET Not valid Valid Valid Valid 92
KC FORCED SET/RESET CANCEL Not valid Valid Valid Valid 93
MM PC MODEL READ Valid Valid Valid Valid 94
TS TEST Valid Valid Valid Valid 94
RP PROGRAM READ Valid Valid Valid Valid 94
WP PROGRAM WRITE Not valid Not valid Not valid Valid 95
MI I/O TABLE GENERATE Not valid Not valid Not valid Valid 95
QQ I/O REGISTER Valid Valid Valid Valid 95
XZ ABORT (command only) Valid Valid Valid Valid 98
C-mode Command List Section 5-1
