Omron SYSMAC CV1000 User Manual

Appendix AStandard Models
112
H-PCF Optical Fiber Cords and Cables with Connectors
The following diagram illustrates the model number for cables with connectors. tension members and power lines
are provided in the cable. Half-lock connectors use the S3200-COCF2511 and are compatible with C200H SYS-
MAC LINK or SYSMAC NET Link Unit connectors. Full-lock connectors use the S3200-COCF2011 and are com-
patible with CV-series SYSMAC LINK or SYSMAC NET and C1000H SYSMAC LINK Link Unit connectors. Full-
lock connectors cannot be used with C200H connectors.
The above connectors cannot be used with C500 SYSMAC NET Link Unit connectors, cable relays, or NSB. Refer
to the SYSMAC NET Link System Manual for appropriate connectors for these applications.
S3200-CNjjj-jj-jj
Cable Length
201 2 m
501 5 m
102 10 m
152 15 m
202 20 m
Blank Over 20 m*
*Specify lengths over 20 m separately when ordering.
Connector Type
20-20 Full-lock connecter on each end
20-25 One full-lock and one half-lock connector
25-25 Full lock connector on each end
Optical Connectors
Name Model
SYSMAC NET: CV500-SNT31
SYSMAC LINK: CV500-SLK11, C1000H-SLK11
SYSMAC BUS/2: CV500-RM211/RT211
S3200-COCF2011
SYSMAC NET: C200H-SNT31
SYSMAC LINK: C200H-SLK11
S3200-COCF2511
SYSMAC NET: C500-SNT31-V4
S3200-LSU03-01E/NSB11-E
S3200-NSUA1-00E/NSUG4-00E
FIT10-IF401
S3200-COCH62M
SYSMAC BUS: 3G2A5-RM001-(P)EV1
3G2A5-RT001/RT002-(P)EV1
3G2A9-ALjj-(P)E
S3200-COCH82
SYSMAC NET Relay (M) Connector S3200-COCF62M
SYSMAC NET Relay (F) Connector S3200-COCF62F
Cable Assembly Tool and Cutter
Name Model
Cable Assembly Tool S3200-CAK1062
Optical Power Tester
Name Model
SYSMAC NET: CV500-SNT31 S3200-CAT2000
SYSMAC LINK: CV500-SLK11
SYSMAC BUS/2: CV500-RM211/RT211
S3200-CAT2700
SYSMAC BUS: 3G2A5-RM001-(P)EV1
3G2A5-RT001/RT002-(P)EV1
S3200-CAT2820
SYSMAC NET: S3200-LSU03-01E
FIT10-IF401
S3200-CAT3200
Note Each Optical Power Tester is provided with a replaceable Head Unit. There is no difference in type among
all Optical Power Testers except for the head unit. This means the S3200-CAT2000 Optical Power Tester,
for example, can be used as the S3200-CAT2700, S3200-CAT2820, or S3200-CAT3200 Optical Power
Tester by just replacing the Head Unit of the S3200-CAT2000 with those for the S3200-CAT2700,
S3200-CAT2820, or S3200-CAT3200.
