The following flowcharts illustrates the above procedure.
Half
duplex
What is to be connected?
Host computer
Does the Host Link Unit
send commands to the
host computer?
No Yes
Specify full du-
plex commu-
nications.
Specify the communications
method.
Set so that no
Xon/Xoff control
will be executed.
Full
duplex
Is Xon/Xoff control
to be executed?
Set so that no
Xon/Xoff control
will be executed.
Set so that no
Xon/Xoff control
will be executed.
Programmable Terminal
Set so that no
Xon/Xoff control
will be executed.
Set the transmission
delay time.
Are data retries to be used
for transmission failures?
Set so that there
will be no data
re-transmission.
Set so that there
will be data re-
transmission.
Set the baud rate, number of stop bits, par-
ity, and data length.
End
Select the full duplex
communications
method.
(See note 1)
(See note 1)
(See note 2)
Note 1. Specify full-duplex communications method and turn OFF the Xon/Xoff con-
trol in the following cases:
• If the Host Link Unit is connected to a host computer and no commands will
be sent from the Host Link Unit to the host computer.
• If a PC is connected.
In the above cases, actual communications control is executed in half du-
plex even though the full duplex communications are specified. If the Host
Link Unit is used simultaneously with the CPU’s host interface, full-duplex
communications must be specified to enable normal communications.
2. Only full-duplex communications are possible for RS-422 communications
at communications port 2.
Host Link Unit Settings and Parameters Section 2-2
