Before executing the RECV(193) instruction, it is necessary to set the following
control data beginning with the first control data word.
15 14 13 12 11 10 9 8 3 2 1 0 Bit
C + 0
Word
C + 1
C + 2
C + 3
C + 4
*10000 0000
7654
Response monitor time (Unit: 0.1 s)
Host Link Unit Communications port no.
Source node number Source unit address
Source network address
Communica-
tions port no.
No. of retries
No. of words to be transferred
1, 2, 3... 1. No. of words to be transferred: Set the total number of words of data to be
transmitted from the host computer.
2. Host Link Unit communications port no.: Set the communications port num-
ber of the Host Link Unit that is connected to the host computer.
3. Source network address: Set the network address of the source node. Set to
00 for communications within the local network.
4. Source node number: Set the source node number. Set to 00 for transmis-
sions within the local PC.
5. Source unit address: Set the source unit address of the Host Link Unit that is
connected to the host computer.
6. Communications port no.: Set the port number of the PC sending the
RECV(193) instruction.
7. No. of retries: Set the upper limit of the number of retries for obtaining a re-
sponse after the RECV(193) instruction is sent.
8. Response monitor time: Set the response monitor time, during which the
Host Link Unit waits for the response.
The setting range of each control data item is as follows:
Item Range
No. of words 0001 to 0100 (1 to 256 words)
Host Link Unit
communications port no.
00 or 01: Communications port 1
02: Communications port 2
Source network address 00: Local network
01 to 7F: Network address (1 to 127)
Source node number 00: Within local PC
01 to 7E: Node number (1 to 126) (SYSMAC NET)
01 to 3E: Node number (1 to 62) (SYSMAC LINK)
Source unit address 10 to 1F: Host Link Unit (unit numbers 1 to 15)
Communications port no. 0 to 7 (0 to 7)
No. of retries 0 to F (0 to 15)
Response monitor time 0000: Default (2 s)
0001 to FFFF (0.1 to 6,553.5 s with 0.1-s increments)
Note In order to execute the RECV(193) instruction properly, it is necessary to pre-
pare a program on the host computer so that the host computer will process the
instruction that the host computer has received and transmit the proper data.
