Response Format
@ W%
Unit no. FCS TerminatorHeader
code
Response
code
*s
x 10
0
x 10
1
x 16
1
x 16
0
Parameters Address (command): Specify the address from which to start searching for the
timer/counter instruction in six digits of BCD.
Timer/Counter instruction (command): Specify in four letters the instruction
used to create the timer/counter (see below).
Timer/Counter number (command): Specify the timer/counter number used
to define the timer/counter.
Timer/Counter instruction
Instruction Timer/Counter
b
OP1 OP2 OP3 OP4
number
T M H W HIGH-SPEED TIMER
WAIT (TMHW<015>)
000 to 0511
(CVM1-CPU01-EV2
C)
T I M W TIMER WAIT
(TIMW<013>)
(C C U0
and CV500)
0000 to 1023 (other
C N T W COUNTER WAIT
(CNTW<014>)
0000
to
1023
(other
CPUs)
T I M H HIGH-SPEED TIMER
(TIMH(015))
T T I M ACCUMULATIVE
TIMER (TTIM(120))
C N T R REVERSIBLE
COUNTER (CNTR(012))
T I M space TIMER (TIM)
C N T space COUNTER (CNT)
Note A total of four letters are required to specify the instruction. Be sure to include a
space where necessary.
