24
SP10-PRO01
0 FILTER VAL
GROUP 1Ć1 2Ć2
Group 1: 1 ms
Group 2: 5 ms
SP10-PRO01-V1
The display will show the settings for groups 1 and 2 when the Programming
Console is connected to an SP10.
0 PC :0Ć1
ProCo:0Ć2
PC settings
Group 1: 0 ms; group 2: 1 ms.
Programming Console settings
Group 1: 0 ms; group 2: 5 ms.
The display will show the settings for groups 1, 2, and 3 when the Program-
ming Console is connected to an SP16 or SP20.
0 PC :0Ć1Ć2
ProCo:0Ć2Ć2
PC settings
Group 1: 0 ms; group 2: 1 ms; group 3: 5 ms.
Programming Console settings
Group 1: 0 ms; group 2: 5 ms; group 3: 5 ms.
Note If a pulse width of less than 150 µs is input, the SP-series CPU and the Pro-
gramming Console will not work properly.
Programming Console Section 2-4
