No.17S010-01
42/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
Restriction of ROI operation
Region 0 is always ON
Region(X+Y) can be enable (On) after sets ON Region (X) and Region (Y).
The following restriction exist to set region’s Width, Height, OffsetX and OffsetY
Width[Region0] = Width[Region1]
Height[Region0] = Height[Region2]
OffsetX[Region0] = OffsetX[Region1]
OffsetY[Region0] = OffsetY[Region2]
Overlapped region setting is invalid
When setting the Horizontal flip, Vertical flip, Horizontal Vertical flip, position of region 0 to 15 are changed.
Please refer to the drawing that follows.
All of selected data outputs as single image data.
If Binning / Decimation is enable, obtained Width and Height values are as “Binning / Decimation” functioned
value. When changing Binning / Decimation settings, the image size and region position are changed.
Please set correct image size and region position after change Binning / Decimation settings.
