No.17S010-01
61/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
Name Description
DeviceCharacterSet Character set used by the strings of the device`s bootstrap registers.
DeviceReset Resets the device to its power up state.
DeviceRegistersStreamingStart Prepare the device for registers streaming without checking for consistency.
DeviceRegistersStreamingEnd Announce the end of registers streaming. This will do a register set validation for
consistency and activate it.
DeviceTemperatureSelector Selects the location within the device, where the temperature will be measured.
DeviceTemperature Device temperature in degrees Celsius (C). It is measured at the location selected by
DeviceTemperatureSelector.
TimestampLatch Latches the current timestamp counter into TimestampLatchValue.
TimestampLatchValue Returns the latched value of the timestamp counter.
Name Description
SensorWidth Effective width of the sensor in pixels.
SensorHeight Effective height of the sensor in pixels.
SensorShutterMode Sets the shutter mode of the device.
WidthMax Maximum width of the image (in pixels). The dimension is calculated after horizontal
binning, decimation or any other function changing the horizontal dimension of the
image.
HeightMax Maximum height of the image (in pixels). This dimension is calculated after vertical
binning, decimation or any other function changing the vertical dimension of the image
BinningSelector Selects which binning engine is controlled by the BinningHorizontal and BinningVertical
features.
BinningHorizontalMode Sets the mode to use to combine horizontal photo-sensitive cells together when
BinningHorizontal is used.
BinningHorizontal Number of horizontal photo-sensitive cells to combine together. This increases the
intensity (or signal to noise ratio) of the pixels and reduces the horizontal resolution
(width) of the image.
BinningVerticalMode Sets the mode used to combine vertical photo-sensitive cells together when
BinningVertical is used.
BinningVertical Number of vertical photo-sensitive cells to combine together. This increases the intensity
(or signal to noise ratio) of the pixels and reduces the vertical resolution (height) of the
image.
DecimationHorizontal Horizontal sub-sampling of the image. This reduces the horizontal resolution (width) of
the image by the specified horizontal decimation factor.
DecimationVertical Vertical sub-sampling of the image. This reduces the vertical resolution (height) of the
image by the specified vertical decimation factor.
RegionSelector Selects the Region of interest to control. The RegionSelector feature allows devices that
are able to extract multiple regions out of an image, to configure the features of those
individual regions independently.
ImageComponentSelector Selects a component to activate data streaming from.
ImageComponentEnable Controls if the selected component streaming is active.
Width Width of the image provided by the device (in pixels).
Height Height of the image provided by the device (in pixels).
OffsetX Horizontal offset from the origin to the region of interest (in pixels).
OffsetY Vertical offset from the origin to the region of interest (in pixels).
