No.17S010-01
63/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
Name Description
PayloadSize Provides the number of bytes transferred for each image or chunk on the stream
channel. This includes any end-of-line, end-of-frame statistics or other stamp data. This
is the total size of data payload for a data block.
Name Description
LineSelector Selects the physical line (or pin) of the external device connector to configure.
LineMode Controls if the physical Line is used to Input or Output a signal.
LineInverter Controls the inversion of the signal of the selected input or output Line.
LineStatus Returns the current status of the selected input or output Line.
LineSource Selects which internal acquisition or I/O source signal to output on the selected Line.
LineMode must be Output.
UserOutputSelector Selects which bit of the User Output register will be set by UserOutputValue.
UserOutputValue Sets the value of the bit selected by UserOutputSelector.
StrobeOutDelay Delay of StrobeOut signal when LineSource is set to StrobeOut(us).
StrobeOutOnTime Duration of StrobeOut signal when LineSource is set to StrobeOut(us).
TriggerOutDelay Delay of TriggerOut signal when LineSource is set to TriggerOut(us).
TriggerOutOnTime Duration of TriggerOut signal when LineSource is set to TriggerOut(us).
LineDeviceResetMode Sets the Line device reset mode.
LineDebounceTime Sets the value of the input line debouncer time.
Name Description
CounterSelector Selects which Counter to configure.
CounterEventSource Select the events that will be the source to increment the Counter.
CounterEventActivation Selects the Activation mode Event Source signal.
CounterResetSource Selects the signals that will be the source to reset the Counter.
CounterResetActivation Selects the Activation mode of the Counter Reset Source signal.
CounterReset Does a software reset of the selected Counter and starts it. The counter starts counting
events immediately after the reset unless a Counter trigger is active. CounterReset can
be used to reset the Counter independently from the CounterResetSource. To disable
the counter temporarily, set CounterEventSource to Off.
CounterValue Reads or writes the current value of the selected Counter.
CounterValueAtReset Reads the value of the selected Counter when it was reset by a trigger or by an explicit
CounterReset command.
CounterDuration Sets the duration (or number of events) before the CounterEnd event is generated.
CounterStatus Returns the current status of the Counter.
CounterTriggerSource Selects the source to start the Counter.
CounterTriggerActivation Selects the activation mode of the trigger to start the Counter.
