No.17S010-01
47/68
STC-MBS43U3V / STC-MCS43U3V / STC-MBS163U3V / STC-MCS163U3V
Product Specifications and Use’s Guide
(*) When the image is flipping for color camera, the pixel array is also flipped.
Reverse X(Off), Y(Off)
00 01 02 03
10 11 12 13
20 21 22 23
30 31 32 33
Reverse X(Off),Y(On)
00 01 02 03
10 11 12 13
20 21 22 23
30 31 32 33
Reverse X(On), Y(Off)
00010203
10111213
20212223
30313233
Reverse X(On), Y(On)
00010203
10111213
20212223
30313233
