4-5SectionOperation Test (TEST)
70
2. Specify
the write end address. If the start address exceeds
the end address,
then data is written only to the start address location.
3. Specify the data.
4. When the TEST Key is pressed, the test menu is shown on the display.
5. When
Key 2 is pressed, the write test is initiated, and if operation is normal,
the write data is displayed.
Note If
operation is abnormal, and error code is displayed (see page
97).
When this happens, use the horizontal cursor keys to display the
error message.
4-5-3 Test Auto Read
Data
is repeatedly read out from any memory area defined by specified start and
end addresses from the DC while it is in motion.
The
step number of the received data can be set to any value in the range 1 to
FF
(256
bytes maximum), enabling a total communications test checking
relation
-
ships between installation positions, speeds, and other parameters.
Operation Procedure
TEST
RESET
3
(Cancel
operation by pressing )
Job specification
(Head no. and Page no.)
TEST
14
(1)
Address
setting
(stare and end addresses)
TAR d21
(2)
RESET
TAR dXX
Test read display
Data
(3)
1, 2, 3...
1. When the TEST Key is pressed, the test menu is shown on the display.
2. Press
Key 3 to select auto read, and T
AR is shown on the display
. This indi
-
cates
the DC waiting condition,
and the indicator on Head 1 or 2 lights at this
time.
3. The DC approaches the operation range, and once processing is com-
pleted,
the data in the location of
the specified address (start address) is dis
-
played.
The Head 1 or 2 indicator now
flashes. When an error code is dis
-
played, use the horizontal cursor keys to display the error message.
Note Ensure
that the start address does not exceed the end
address before pressing
the TEST Key to read data from several addresses.
