 V680-D2KF67M
 Measurement Conditions
Antenna RF Tag Communications range
V680-HS52
V680S-D2KF67M
with metal on back (steel)
Read 1.0 to 16.0 mm (Axis offset: 2)
Write 1.0 to 16.0 mm (Axis offset: 2)
V680-HS63
V680S-D2KF67M
with metal on back (steel)
Read 6.0 to 25.0 mm (Axis offset: 10)
Write 6.0 to 25.0 mm (Axis offset: 10)
V680-HS65
V680S-D2KF67M
with metal on back (steel)
Read 5.0 to 25.0 mm (Axis offset: 10)
Write 5.0 to 25.0 mm (Axis offset: 10)
V680S-D2KF67M
Non-metallic material
Metallic material
V680-HS52
V680-HS63
Metallic material
V680S-D2KF67M
Non-metallic material
V680-HS65
V680S-D2KF67M
Metallic material
Metallic material
