112
SECTION 7
Specifications and Dimensions
RFID System
User's Manual
SECTION 7
Appendices
 V680S-D2KF67
 Measurement Conditions
Antenna RF Tag Communications range
V680-HS52 V680S-D2KF67
Read 1.0 to 17.0 mm (Axis offset: 2)
Write 1.0 to 17.0 mm (Axis offset: 2)
V680-HS63 V680S-D2KF67
Read 7.0 to 30.0 mm (Axis offset: 10)
Write 7.0 to 30.0 mm (Axis offset: 10)
V680-HS65 V680S-D2KF67
Read 5.0 to 42.0 mm (Axis offset: 10)
Write 5.0 to 42.0 mm (Axis offset: 10)
V680S-D2KF67
Non-metallic material
V680-HS52
V680-HS63
V680S-D2KF67
Non-metallic material
V680-HS65
V680S-D2KF67
Metallic material
Non-metallic material
(Examples: Resin, plastic, wood, etc.)
Non-metallic material
(Examples: Resin, plastic, wood, etc.)
Non-metallic material
(Examples: Resin, plastic, wood, etc.)
