14
SECTION 1
Part Names and Functions
RFID System
User's Manual
SECTION 1
Product Overview
■ Operation Indicators
 DEV (Device Status)
The DEV indicator displays the Unit status.
 RMT (Remote Status)
The RMT indicator displays the FL Remote network status.
 T/R
The TR indicator displays the RF Tag communications status.
 NORMAL/ERROR
■ Data Display and Error Code Display
The Data Display shows the first byte of data that was read or written when communications ends nor-
mally. It displays the error code if communications ends in an error.
For details, refer to the RFID-related Errors.
p.72
Status Definition
Lit green
Normal
Lit red
Fatal error
Flashing red
Non-fatal error
Not lit
No power
Status Definition
Lit green
Adding link/Participating in remote communications
Flashing green
Adding link/Leaving remote communications
Flashing green and red
Adding link/Remote classification error or setting error
Lit red
Duplicate node address or duplicate common address
Flashing red
Withdrawn from link
Not lit
Not linked.
Status Definition
Lit yellow
RF Tag is communicating
Not lit
Standby
Status Definition
Lit green
Normal end
Lit red
Error end
Not lit
Standby
Status Definition
Lit green
Data displayed.
Lit red
System error displayed.
Flashing red
Error code displayed.
Not lit
Display turned OFF.
