Detailed Command Settings
SECTION 5
Communications
DATA FILL
■ Master Unit to FL Remote ID
■ FL Remote ID to Master Unit
When there is an RF Tag service life warning, the Normal End Bit will be turned ON and the Error End Bit will not be
turned ON.
■ Master Unit to FL Remote ID Settings Example
Example: Filling with FF hex to 16 bytes from Address 6 hex (2 Blocks 8 Bytes/Block)
Signal Bit length Value Description
CMD 4 0100
B DATA FILL
LEN 4 1 to F hex
0 hex
Number of blocks to process (specified number of blocks x 8 bytes)
If the number of blocks is 0, all memory after the DATA FILL start address will
be selected.
ADDR 16 0000 to FFFF hex DATA FILL start address
OD 0 8 --- DATA FILL data
Data between OD1 and OD3 is invalid.
Signal Bit length Value Description
NORMAL 1 0 or 1 Set to 1 when operation is ended normally.
ERROR 1 0 or 1 The corresponding bit is set to 1 if the command ends in an error.
ERR_SUB0 to
ERR_SUB6,
ERR_SUB13 to
ERR_SUB15
1 0 or 1 The corresponding bit is set to 1 if RF Tag communications end in an error.
The details of the error are also given.
ERR_SUB7 1 0 or 1 The corresponding bit is set to 1 if there is an RF Tag service life warning.
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit
CIO
+0
0000000000000110
CIO
+1
CIO
+2
CIO
+3
*****00001000010
0000000011111111
0000000000000000
DATA FILL 2 Blocks
Address 6 hex
Fixed FF hex
Fixed Fixed
Change according to the setting.
Fixed
To Next Page
