66
SECTION 5
Detailed Command Settings
RFID System
User's Manual
SECTION 5
Communications
NOISE MEASUREMENT
■ Master Unit to FL Remote ID
■ FL Remote ID to Master Unit
■ Master Unit to FL Remote ID Settings Example
Signal Bit length Value Description
CMD 4 1000
B NOISE MEASUREMENT
Signal Bit length Value Description
NORMAL 1 0 or 1 Set to 1 when operation is ended normally.
ERROR 1 0 or 1 The corresponding bit is set to 1 if the command ends in an error.
ERR_SUB * 1 0 or 1 The corresponding bit is set to 1 if RF Tag communications end in an error. The
details of the error will also be given.
ID 32 --- Result of noise measurement
ID0: Average noise level (00 hex to 99: decimal)
ID1: Maximum noise level (00 hex to 99: decimal)
ID2: Minimum noise level (00 hex to 99: decimal)
ID3: Always 00 hex
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Bit
CIO
+0
0000000000000000
CIO
+1
CIO
+2
CIO
+3
*****00010000000
0000000000000000
0000000000000000
Fixed
Fixed
Fixed
Fixed
Change according to the setting.
Fixed
NOISE MEASUREMENT
