 Dimensions
V680-HS63-W
V680-HS63-R
Case material ABS resin
Fill resin Epoxy resin
Cable PVC (gray)
Case material ABS resin
Fill resin Epoxy resin
Cable PVC (black)
(Unit: mm)
Connector
Ferrite core
Insulation cover
37
50
30
16.5 dia.
Coaxial cable, 5.5 dia.,
standard length: 2 m
Operation indicator
16.8 dia.
14.5 dia.
Two, M4 or 4.5-dia. holes
Antenna
53
27
6
5
Coil center
Note: Mounting Hole Dimensions
40
5
28±0.1
16.8 dia.
(Unit: mm)
14.5 dia.
Connector
Ferrite core
Insulation cover
37
50
30
16.5 dia.
Coaxial cable, 5.3 dia.,
standard length: 2 m
Operation indicator
Antenna
Note: Mounting Hole Dimensions
Coil center
Two, M4 or 4.5-dia. holes
40
28±0.1
53
27
6
5
