SECTION 7
Specifications and Dimensions
RFID System
User's Manual
SECTION 7
Appendices
Dimensions
V680-D1KP66T/-D1KP66MT
V600-A86 Attachment
RF Tag Heat Resistivity
² Storing RF Tags under high temperatures will adversely affect the performance of the internal parts
and the service life of the RF Tags.
² An LTPD of 10% was determined during the evaluation for RF Tags that reached the end of their life
after testing under the following test conditions.
LTPD: Lot tolerance percent defective
The lower limit of the malfunction rate for lots to be considered unacceptable during reliability testing.
Case material PPS resin
Case material PPS resin
Heat cycle 10C/150C, 30 minutes each for 1,000 cycles
10C/180C, 30 minutes each for 200 cycles
High temperatures 150C, 1,000 hours
180C, 200 hours
(Unit: mm)
25±0.2
Four, R8
Four, R4
34
32
32
34
25±0.2
35±0.1
Two, M3
25±0.2
25±0.2
Two, 3.5 dia.
Two, 6 dia.
Mouting Hole Dimensions
(Unit: mm)
25±0.2
Two, 4 dia.
Four, R5.5
34
37
37
34
25±0.2
Two, M3
25±0.2
25±0.2
15
15
10
16
3.5
4
