 V680-D1KP66T-SP
 General Specifications
 Dimensions
Item Specifications
Memory capacity 1,000 bytes
Memory type EEPROM
Data Retention 10 years after writing (85C or less)
Write Endurance 100,000 times per block (25C)
Ambient operating temperature When communicating: 25 to 70C (with no icing)
When not communicating: 40 to 110C (with no icing)
Ambient operating humidity 35% to 95% (with no condensation)
Ambient storage temperature 40 to 110C (with no icing)
Ambient storage humidity 35% to 95% (with no condensation)
Vibration resistance 10 to 2,000 Hz, 1.5-mm double amplitude at 150 m/s
2
in X, Y, and Z directions ten
sweeps each for 15 minutes
Shock resistance 500 m/s
2
, 3 times each in X, Y, and Z directions (Total: 18 times)
Dimensions 95  36.5  6.5 (W H D) mm (excluding protruding parts)
Degree of protection IP67
Material External coating: Fluororesin (PFA)
RF Tag body: PPS resin
Weight Approx. 20 g
Mounting method Two M5 screws
Two, 5.5 dia.
(Mounting hole)
Four, R6
1.3
6.5 2.5 max.
Two, M5
80±0.2
80±0.2
34
95
3436.5
Mounting Hole Dimensions
PFA resinCase material
(Unit: mm)
