Section 6 Using Field Extension Mode
Section 6
Functions
139
RFID System
User's Manual
(Modbus TCP)
Enabling Field Extension Mode
1. Connect all of the Reader/Writers with Ethernet Cables and turn ON the power supplies.
Set a unique IP address for each Reader/Writer in advance.
Refer to Section 5 Preparations for Communications.
2. Start a Web browser on your computer.
3. In the address field on the Web browser operation window, enter the IP address of the Master Reader/
Writer (here, 192.168.1.200).
4. Display the RF Tag Communications Settings View, set the RF Tag communications option to Once or
Auto, and then click the Set Button.
If you specify the FIFO Trigger communications option, multi-Reader/Writer operation will be enabled and a multi-
Reader/Writer execution status error will occur when you restart.
To Next Page
