Section 8 Operation Interface
RFID System
User's Manual
(Modbus TCP)
Section 8
Web Browser Interface
Network Settings View
TCP/IP Setting
If you change the network settings, restart the Reader/Writer. The new settings will be effective after a restart of the
Reader/Writer.
When you restart the Reader/Writer after you change the IP address, Web browser can not reconnect to the Reader/
Writer. If you re-specified the new IP address in the address field of the Web browser, the screen will be appeared.
The error message is displayed if you change the configuration during the Reader/Writer is executing RF tag
communication or Noise measurement.
Item name Description Setting range Default
IP address IP address --- 192.168.1.200
Subnet mask Subnet mask address --- 255.255.255.0
Gateway address Gateway address --- 192.168.1.254
Device name 63 ASCII characters max. 63 ASCII characters max. None
Click this button to set
the displayed values.
To Next Page
