48
Section 1 Data Characteristics
RFID System
User's Manual
(Modbus TCP)
Section 1
Product Overview
Data Characteristics
Communications Range Specifications
V680S-HMD63-ETN
Reader/Writer RF Tag Communications distance specification
V680S-HMD63-
ETN (mounted to
metallic material)
V680-D1KP54T (mounted to non-metallic material) Read 0.0 to 24.0 mm (axis offset: ±10 mm)
Write 0.0 to 20.0 mm (axis offset: ±10 mm)
V680-D1KP66T (mounted to non-metallic material) Read 0.0 to 30.0 mm (axis offset: ±10 mm)
Write 0.0 to 25.0 mm (axis offset: ±10 mm)
V680-D1KP66MT (mounted to metallic material) Read 0.0 to 25.0 mm (axis offset: ±10 mm)
Write 0.0 to 20.0 mm (axis offset: ±10 mm)
V680-D1KP66T-SP (mounted to non-metallic material) Read 0.0 to 25.0 mm (axis offset: ±10 mm)
Write 0.0 to 20.0 mm (axis offset: ±10 mm)
V680S-D2KF67 (mounted to non-metallic material) Read 7.0 to 40.0 mm (axis offset: ±10 mm)
Write 7.0 to 40.0 mm (axis offset: ±10 mm)
V680S-D2KF67M (mounted to metallic material) Read 6.0 to 30.0 mm (axis offset: ±10 mm)
Write 6.0 to 30.0 mm (axis offset: ±10 mm)
V680S-D8KF67 (mounted to non-metallic material) Read 7.0 to 40.0 mm (axis offset: ±10 mm)
Write 7.0 to 40.0 mm (axis offset: ±10 mm)
V680S-D8KF67M (mounted to metallic material) Read 6.0 to 30.0 mm (axis offset: ±10 mm)
Write 6.0 to 30.0 mm (axis offset: ±10 mm)
