234
Section 8 Operation Interface
RFID System
User's Manual
(Modbus TCP)
Section 8
Web Browser Interface
Reboot
If you click the Reboot Button on any of the operation views, a Confirm Reboot Dialog Box is
displayed.
If you click the Reboot Button, a Confirm Reboot Dialog Box will be displayed.
The following dialog box is displayed after the Reader/Writer has finished rebooting.
Click the OK Button to connect to the Reader/Writer.
The following dialog box is displayed after reconnecting to the Reader/Writer. Click the OK Button.
When re-connection goes wrong and an error message is displayed, check connection with the Reader/Writer and
reboot a Web browser.
After re-connection, displays the “Status” window.
Click this button to reboot
the Reader Writer.
Click this button to cancel
rebooting the Reader Writer.
To Next Page
