Omron V680 Series User Manual

148
Section 6 Using Field Extension Mode
RFID System
User's Manual
(Modbus TCP)
Section 6
Functions
 Enabling High-speed Traveling Mode
1. Connect all of the Reader/Writers with Ethernet Cable and turn ON the power supplies.
Set a unique IP address for each Reader/Writer in advance.
Refer to Section 5 Preparations for Communications.
2. Start a Web browser on your computer.
3. In the address field on the Web browser operation window, enter the IP address of the Master Reader/
Writer (here, 192.168.1.200).
4. Display the RF Tag Communications Settings View, set the RF Tag communications option to Auto,
and then click the Set Button.
If you specify the Once or FIFO Trigger communications option, multi-Reader/Writer operation will be enabled and a
multi-Reader/Writer execution status error will occur when you restart.
http:// (IP address)
