Section 7 Message Details
RFID System
User's Manual
(Modbus TCP)
Section 7
Host Communications Specifications
 GET FIRMWARE VERSION
The query reads the firmware version from the Reader/Writer.
 Query Format
 Response Format
Normal Response
Error Response
 Execution Example
Reading the Firmware Version Information when the Run Program Version Is 1.2.3 and the Safe
Program Version Is 1.2.2
TX: 000000000006FF03C0000006
RX: 00000000000FFF030C000100020003000100020002
Parameter Description
Register address The register address (C000 hex) that specifies the firmware version.
Word count The number of words in the firmware version information to read (0006 hex)
Parameter Description
Byte count The number of bytes in the firmware version information (0C hex)
Firmware version
information
Major version of Run Mode program 0000 to 0099 hex (BCD)
Minor version of Run Mode program 0000 to 0099 hex (BCD)
Revision of Run Mode program 0000 to 9999 hex (BCD)
Major version of Safe Mode program 0000 to 0099 hex (BCD)
Minor version of Safe Mode program 0000 to 0099 hex (BCD)
Revision of Safe Mode program 0000 to 9999 hex (BCD)
Parameter Description
Exception code For details, refer to Exception Code Table in this section.
p.167
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8 Byte 9 Byte 10 Byte 11
Transaction
identifier
Protocol identifier Field length
Unit
identifier
Function
code
Register address Word count
X X 0000 hex 0006 hex FF hex 03 hex C000 hex 0006 hex
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte -5 Byte 6 Byte 7 Byte 8 Byte 9 ··· Byte 20
Transaction
identifier
Protocol identifier Field length
Unit
identifier
Function code Byte count Firmware version information
XX 0000 hex 000F hex FF hex 03 hex 0C hex 12 bytes
Byte 9 Byte 10 Byte 11 Byte 12 Byte 13 Byte 14 Byte 15 Byte 16 Byte 17 Byte 18 Byte 19 Byte 20
Major version of
Run Mode program
Minor version of
Run Mode program
Revision of
Run Mode program
Major version of
Safe Mode program
Minor version of
Safe Mode program
Revision of
Safe Mode program
2 bytes 2 bytes 2 bytes 2 bytes 2 bytes 2 bytes
Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
Transaction
identifier
Protocol identifier Field length
Unit
identifier
Function
code
Exception
code
X X 0000 hex 0003 hex FF hex 83 hex 1 byte
