Omron V680 Series - Page 317

RF Tag Installation Precautions
Section 11
Section 11
Appendices
315
RFID System
User's Manual
(Modbus TCP)
 Measurement Conditions
• V680S-HMD64-ETN and V680S-D2KF68M
Horizontally
• V680S-HMD64-ETN and V680S-D2KF68M
Vertically
• V680S-HMD66-ETN and V680S-D2KF68M
Horizontally
• V680S-HMD66-ETN and V680S-D2KF68M
Vertically
Non-metallic material
Reader/Writer
RF Tag
Metallic material
Non-metallic material
Reader/Writer
RF Tag
Metallic material
Non-metallic material
Reader/Writer
Metallic material
RF Tag
Non-metallic material
Reader/Writer
Metallic material
RF Tag
