50
Section 1 Data Characteristics
RFID System
User's Manual
(Modbus TCP)
Section 1
Product Overview
V680S-HMD64-ETN
You can use the V680S-D8KF6@ with Reader/Writers with firmware version 2.00 or higher.
Reader/Writer RF Tag Communications Range Specification
V680S-HMD64-ETN
(mounted to metallic material)
V680-D1KP54T
(mounted to non-metallic material)
Read 0.0 to 33.0 mm (axis offset: ±10 mm)
Write 0.0 to 28.0 mm (axis offset: ±10 mm)
V680-D1KP66T
(mounted to non-metallic material)
Read 0.0 to 47.0 mm (axis offset: ±10 mm)
Write 0.0 to 42.0 mm (axis offset: ±10 mm)
V680-D1KP66MT
(mounted to metallic material)
Read 0.0 to 35.0 mm (axis offset: ±10 mm)
Write 0.0 to 30.0 mm (axis offset: ±10 mm)
V680-D1KP66T-SP
(mounted to non-metallic material)
Read 0.0 to 42.0 mm (axis offset: ±10 mm)
Write 0.0 to 37.0 mm (axis offset: ±10 mm)
V680-D1KP58HTN Read 7.5 to 75.0 mm (axis offset: ±10 mm)
Write 7.5 to 75.0 mm (axis offset: ±10 mm)
V680S-D2KF67
(mounted to non-metallic material)
Read 5.0 to 65.0 mm (axis offset: ±10 mm)
Write 5.0 to 65.0 mm (axis offset: ±10 mm)
V680S-D2KF67M
(mounted to metallic material)
Read 3.0 to 40.0 mm (axis offset: ±10 mm)
Write 3.0 to 40.0 mm (axis offset: ±10 mm)
V680S-D8KF67
(mounted to non-metallic material)
Read 5.0 to 65.0 mm (axis offset: ±10 mm)
Write 5.0 to 65.0 mm (axis offset: ±10 mm)
V680S-D8KF67M
(mounted to metallic material)
Read 3.0 to 40.0 mm (axis offset: ±10 mm)
Write 3.0 to 40.0 mm (axis offset: ±10 mm)
V680S-D2KF68
(mounted to non-metallic material)
Read 7.5 to 75.0 mm (axis offset: ±10 mm)
Write 7.5 to 75.0 mm (axis offset: ±10 mm)
V680S-D2KF68M
(mounted to metallic material)
Read 5.5 to 55.0 mm (axis offset: ±10 mm)
Write 5.5 to 55.0 mm (axis offset: ±10 mm)
V680S-D8KF68
(mounted to non-metallic material)
Read 7.5 to 75.0 mm (axis offset: ±10 mm)
Write 7.5 to 75.0 mm (axis offset: ±10 mm)
V680S-D8KF68M
(mounted to metallic material)
Read 5.5 to 55.0 mm (axis offset: ±10 mm)
Write 5.5 to 55.0 mm (axis offset: ±10 mm)
