Omron V680 Series User Manual

Section 4 Installation
Section 4
Installation and Connections
RFID System
User's Manual
(Modbus TCP)
83
 V680-D1KP66T-SP
Mount the RF Tag using M5 screws and washers. The tightening torque is 1.2 N·m.
There are no restrictions on the mounting direction for the RF Tag or the direction of RF Tag travel in
respect to the Reader/Writer.
Refer to RF Tag Installation Precautions in Section 11 Appendices for information on the effect of metal at the back surface,
Mutual Interference of RF Tags and Influence of Inclination of the V680-D1KP66T-SP.
p.283
Mounting Hole Dimensions
Two, M5 hoses
80±0.2
