96
Section 5 Setting Communications Conditions
RFID System
User's Manual
(Modbus TCP)
Section 5
Preparations for Communications
Setting the IP Address on the Computer with Windows 7 or Windows 10
1. Open the Control Panel, and select Network and Internet and then Network and Sharing Center.
2. Select Change adapter settings and then right-click Local Area Connection.
3. Right-click Local Area Connection and select Properties.
4. Select Internet Protocol Version 4 (TCP/IPv4) and then click the Properties Button.
5.
Select the Use the following IP address Option, make the following settings, and then click the OK Button.
Host Device Setting Example
IP address : 192.168.1.100
Subnet mask : 255.255.255.0
This example changes the last part of the IP address of the host device to a value other than 200 (i.e., 1 to 199 or 201to
254). Values of 0 and 255 cannot be used.
6. Click the OK Button to close the Internet Protocol Version 4 (TCP/IPv4) Properties Dialog Box.
To Next Page
