63
V700-L21
User's Manual
Section 5
5.2 How to set up parameters
Section 5
Setup Mode
5.2 How to set up parameters
Various parameters are set up using a terminal software loaded into an upstream controller (PC/AT)
connected to the SECS port of CIDWR controller. The communications parameters for data transaction
between the upstream controller and CIDRW controller are fixed and cannot be altered on the CIDWR
controller side. On the terminal software side, set up the communications parameters, transmission code,
indications, etc., as listed below:
Once entering setup mode, the basic screen below will appear on the terminal display of the upstream
controller.
*<"Modelnumber"><"SoftwareRevisionLevel", "HardwareRevisionLevel">
The setting-capable parameters are as listed below:
■ Parameter list
Baud rate 9600 bps
Date length 8 bit
Parity EVEN
Stop bit 1
Communication control None
Transmission code Add a line feed character (LF) to the end of line (ENTER is input).
Indication Local echo
SETUP_START <L21 ><XXX.XX,YYY.YY>
Category Parameter Tag name Default Range
Protocol Baud rate (BAUD) S_BAUD 9600 1200,2400,4800,9600,19200,
38400,57600,115200
Protocol Device ID (DEVID) S_DEVID 0 0 - 32767
Protocol Inter-character timeout (T1) S_T1 0.5s 0.1 - 10s
Protocol Protocol timeout (T2) S_T2 10s 0.2 - 25s
Protocol Reply timeout (T3) S_T3 45s 1 - 120s
Protocol Inter-block timeout (T4) S_T4 45s 1 - 120s
Protocol Retry limit (RTY) S_RTY 3 0 - 31
Protocol Master/slave (M/S) S_MS M: Master M: Master
S: Slave
SECS Dual block detection S_DB 1: Perform 1: Perform
2: Not perform
SECS Source ID S_SRC 0 0 - 32767
SECS Single block No. S_BNO 1 0,1
Service Baud rate to link unit C_BAUD 9600 9600,19200,38400
Service Number of heads count C_HEAD 0 0 - 31
0 : Auto count
1 - 31 : Number of heads specified
