Data
• Reference Data (available to read out/write in)
Regis-
ter No.
Bit Description
0000H Reserved
0001H
0 Run Command 1: Run 0: Stop
1 Reverse Run Command 1: Reverse run 0: Forward run
2 External fault 1: Fault (EFO)
3 Fault Reset Command 1: Reset Command
4 Multi-function input reference 1 (Function selected by n050)
5 Multi-function input reference 2 (Function selected by n051)
6 Multi-function input reference 3 (Function selected by n052)
7 Multi-function input reference 4 (Function selected by n053)
8 Multi-function input reference 5 (Function selected by n054)
9 Multi-function input reference 6 (Function selected by n055)
A Multi-function input reference 7 (Function selected by n056)
B-F (Not used)
0002H Frequency reference (unit: n152)
0003H V/f gain (1000/100 %) Setting range: 2.0 to 200.0 %
0004H-
0006H
Reserved
0007H
Analog output terminal AM output setting
Setting range: 0 to 1100
[0 to 11 V output/0 to 1100 (when Monitor Gain (n067) = 1.00)]
Note: Enabled only when n065 is set to 0 (analog monitor output) and
n066 is set to 8 (data output via communications).
0008H Reserved
0009H
0
Multi-function output reference 1
(Effective when n057=18)
(1: MA ON, 0: MA OFF)
1
Multi-function output reference 2
(Effective when n058=18)
(1: P1 ON, 0: P1 OFF)
2
Multi-function output reference 3
(Effective when n059=18)
(1: P2 ON, 0: P2 OFF)
3-F (Not used)
