6 Programming Features
149
Note: Write in ā0ā for an unused bit. Never write in data for the reserved reg-
ister.
* Codes that cannot be expressed on 7-segment LEDs will be displayed as
"ā".
000AH
Pulse train output terminal AM output setting
Setting range: 0 to 14400
(0 to 14,400 Hz output/0 to 14400 [set in 1-Hz increments])
Note: Enabled only when n065 is set to 1 (pulse monitor output) and n150
is set to 50 (data output via communications).
000BH
PLC alarm/error setting
0 PLC alarm 1
1: PLC alarm 1 (PA1 flashes on Dig-
ital Operator)
1 PLC alarm 2
1: PLC alarm 2 (PA2 flashes on Dig-
ital Operator)
2 PLC error 1
1: PLC error 1 (PE1 displayed on
Digital Operator)
3 PLC error 2
1: PLC error 2 (PE2 displayed on
Digital Operator)
4-F (Not used)
000C
H
Digital Operator
0-6 Digital Operator 7-segment LED 1st digit display data (ASCII)
7-D Digital Operator 7-segment LED 2nd digit display data (ASCII)
E-F (Not used)
000D
H
Digital Operator
0-6 Digital Operator 7-segment LED 3rd digit display data (ASCII)
7-D Digital Operator 7-segment LED 4th digit display data (ASCII)
E-F (Not used)
000EH
,
001FH
Reserved
Regis-
ter No.
Bit Description
