150
• Simultaneous Broadcasting Data (available only for write in)
Bit signals not defined as the broadcast operation signals are used as
the local station data signals.
• Monitor Data (available only for read out)
Register
No.
Bit Description
0001H
0 Run Command 1: Run 0: Stop
1 Reverse Run Command 1: Reverse run 0: Forward run
2 (Not used)
3 (Not used)
4 External fault 1: Fault (EFO)
5 Fault Reset Command 1: Fault Reset
6-F (Not used)
0002H
Frequency reference 30000/100 % fixed unit
(Data is converted into 0.01 Hz inside the Inverter, and fractions
are rounded off.)
Register
No.
Bit Description
0020H
Status signal
0 Run Command 1: Run 0: Stop
1 Reverse Run Command 1: Reverse run 0: Forward run
2 Inverter operation ready 1: Ready 0: Not ready
3 Fault 1: Fault
4 Data setting error 1: Error
5 Multi-function output 1 (1: MA ON 0: MA OFF)
6 Multi-function output 2 (1: P1 ON 0: P1 OFF)
7 Multi-function output 3 (1: P2 ON 0: P2 OFF)
8-F (Not used)
To Next Page
