154
0038H
PID feedback value (100 % /Input equivalent to max. output frequency;
10/1 %; without sign)
0039H PID input value (±100 %/±Max. output frequency; 10/1 %; with sign)
003AH PID output value (±100 %/±Max. output frequency; 10/1 %; with sign)
003BH-
003CH
Reserved
003DH
Communications error
0 CRC error
1 Data length fault
2(Not used)
3 Parity error
4 Overrun error
5 Framing error
6 Timeover
7(Not used)
003EH-
00FFH
Reserved
0075H
Analog input terminal FR input value
(0.0% to 100.0%/0 to 10 V input,
0.0% to 100.0%/4 to 20 mA input,
0.0% to 100.0%/0 to 20 mA input)
0076H
Pulse train input terminal RP input value
(1 Hz/1)
0077H
Digital Operator potentiometer input value
(0.0% to 100.0%/Minimum to Maximum)
0078H
Digital Operator terminal CN2-1 (voltage input) input value
(0.0% to 100.0%/0 to 10 V input)
0079H
Digital Operator terminal CN2-2 (current input) input value
(0.0% to 100.0%/4 to 20 mA input)
007AH
Digital Operator key input status
0(Not used)
1 The DATA/ENTER key is being pressed.
2 The UP key is being pressed.
3 The DOWN key is being pressed.
4 The RUN key is being pressed.
5 The STOP/RESET key is being pressed.
6-F Not used (always 0)
Register
No.
Bit Description
