6 Programming Features
153
002CH
Inverter status
0 Run 1: Run
1 Zero-speed 1: Zero-speed
2 Frequency agreed 1: Agreed
3 Minor fault (Alarm is indicated)
4 Frequency detection 1 1: Output frequency ≤ (n095)
5 Frequency detection 2 1: Output frequency ≥ (n095)
6 Inverter operation ready 1: Ready
7 Undervoltage detection 1: Undervoltage detection
8 Baseblock 1: Inverter output baseblock
9
Frequency reference mode 1: Other than communications
0: Communications
A
Run Command mode 1: Other than communications
0: Communications
B Overtorque detection 1: Detection or overtorque fault
C
Undertorque detection 1: Detection or undertorque
fault
D Fault retry
E
Fault (Including MEMOBUS communications timeover)
1: Fault
F MEMOBUS communications timeover 1: Timeover
002DH
Multi-function
output
0 MA 1: ON 0: OFF
1 P1 1: ON 0: OFF
2 P2 1: ON 0: OFF
3-F (Not used)
002EH
Inverter
Status
0 Frequency reference loss 1: Frequency reference loss
1-F (Not used)
002FH-
0030H
Reserved
0031H Main circuit DC voltage (1/1 V)
0032H Torque monitor (1/1 %; 100 %/Motor rated torque; with sign)
0033H-
0036H
(Not used)
0037H Output Power (1/1 W: with sign)
Register
No.
Bit Description
To Next Page
