220
Multi-function
Input
Seven of the following input signals are selectable: Forward Run Com-
mand, Reverse Run Command, Forward/Reverse Run (3-wire sequence)
Command, Fault Reset, external fault, multi-step speed operation, Jog
Command, acceleration/deceleration time select, External Baseblock,
Speed Search Command, Acceleration/Deceleration Hold Command,
LOCAL/REMOTE selection, communication/control circuit terminal selec-
tion, emergency stop fault, emergency stop alarm, Up/Down Command,
self-test, PID control cancel, PID integral reset/hold, Inverter overheat
alarm
Multi-function
Output
*5
The following output signals are selectable (1 NO/NC contact output, 2
photocoupler outputs):
Fault, running, zero speed, frequency agree, frequency detection, over-
torque detection, undertorque detection, minor error, baseblock, operat-
ing mode, Inverter run ready, fault retry, UV, speed search, data output
through communications, PID feedback loss detection, frequency refer-
ence loss, Inverter overheat alarm
Standard Functions Voltage vector control, full-range automatic torque boost, slip compensa-
tion, DC injection braking current/time at startup/stop, frequency refer-
ence bias/gain, MEMOBUS communications (RS-485/422, max. 19.2
kbps), PID control, energy-saving control, constant copy, frequency refer-
ence with built-in potentiometer, unit selection for frequency reference
setting/display, multi-function analog input
Status Indica-
tors
RUN and ALARM provided as standard indicators
Digital
Operator
(JVOP-140)
Monitor frequency reference, output frequency, and output current provid-
ed.
Terminals Main circuit: screw terminals
Control circuit: plug-in screw terminal
Wiring Distance
between Inverter and
Motor
100 m (328 ft) or less
*6
Enclosure
Open chassis (IP20, IP00)
*7
, or enclosed wall-mounted NEMA 1
(TYPE 1)
*8
Cooling Method Cooling fan is provided for the following models:
400 V, 1.5 kW or larger Inverters (3-phase)
Other models are self-cooling.
Ambient Temperature Open chassis (IP20, IP00): −10 to 50 °C (14 to 122 °F)
Enclosed wall-mounted NEMA 1 (TYPE 1): −10 to 40 °C (14 to 105°F)
(not frozen)
Humidity 95 % or less (non-condensing)
Storage Temperature
*9
−20 to 60 °C (−4 to 140 °F)
Location Indoor (free from corrosive gases or dust)
Elevation 1,000 m (3,280 ft) or less
Vibration
Up to 9.8 m/s
2
(1G) at 10 to less than 20 Hz,
up to 2 m/s
2
(0.2G) at 20 to 50 Hz
Voltage Class 400 V 3-phase
Model
CIMR-
V7AZ
3-phase 40P2 40P4 40P7 41P5 42P2 43P0 44P0 45P5 47P5
Single-phase---------
Output Functions
Input SignalsOutput Signals
Other Functions
Indications
Environmental Condi-
To Next Page
