230
Note: Remove the top and bottom covers so that Inverters of 5.5/7.5 kW (200/
400 V Classes) can be used as IP00.
200 V
single-
phase
0.1 68
(2.68)
128
(5.04)
76
(2.99)
56
(2.20)
118
(4.65)
5
(0.20)
M4 0.6
(1.32)
3.7 10.4 14.1 1
0.25 68
(2.68)
128
(5.04)
73
(2.99)
56
(2.20)
118
(4.65)
5
(0.20)
M4 0.7
(1.54)
7.7 12.3 20.0 1
0.55 68
(2.68)
128
(5.04)
131
(5.16)
56
(2.20)
118
(4.65)
5
(0.20)
M4 1.0
(2.20)
15.8 16.1 31.9 1
1.1 108
(4.25)
128
(5.04)
140
(5.51)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.5
(3.31)
28.4 23.0 51.4 2
1.5 108
(4.25)
128
(5.04)
156
(6.14)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.5
(3.31)
53.7 29.1 82.8 2
2.2 140
(5.51)
128
(5.04)
163
(6.42)
128
(5.04)
118
(4.65)
5
(0.20)
M4 2.2
(4.84)
64.5 49.1 113.6 2
4.0 170
(6.69)
128
(5.04)
180
(7.09)
158
(6.22)
118
(4.65)
5
(0.20)
M4 2.9
(6.38)
98.2 78.2 176.4 2
400 V
3-phase
0.37 108
(4.25)
128
(5.04)
92
(3.62)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.0
(2.20)
9.4 13.7 23.1 2
0.55 108
(4.25)
128
(5.04)
110
(4.43)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.1
(2.43)
15.1 15.0 30.1 2
1.1 108
(4.25)
128
(5.04)
140
(5.51)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.5
(3.31)
30.3 24.6 54.9 2
1.5 108
(4.25)
128
(5.04)
156
(6.14)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.5
(3.31)
45.8 29.9 75.7 2
2.2 108
(4.25)
128
(5.04)
156
(6.14)
96
(3.78)
118
(4.65)
5
(0.20)
M4 1.5
(3.31)
50.5 32.5 83.0 2
3.0 140
(5.51)
128
(5.04)
143
(5.63)
128
(5.04)
118
(4.65)
5
(0.20)
M4 2.1
(4.62)
58.2 37.6 95.8 2
4.0 140
(5.51)
128
(5.04)
143
(5.63)
128
(5.04)
118
(4.65)
5
(0.20)
M4 2.1
(4.62)
79.9 49.2 129.1 2
5.5 180 260 170 164 244 8 M5 4.8 168.8 87.7 256.5 3
7.5 180 260 170 164 244 8 M5 4.8 209.6 99.3 308.9 3
Voltage
class
Capaci-
ty (kW)
W H D W1 H1 H2 d Mass Heat Loss (W) Fig.
Heat-
sink
Unit Total
