10 Conformance to CE Markings
249
Installation and Wiring of Inverter and Noise Filter
(Model: CIMR-V720P1 to 27P5),
(Model: CIMR-V740P1 to 45P5)
L1 L2 L3
L1 L2 L3
E
E
WUV
TRS
PE
Control Panel
3-phase Noise Filter
Grounding
Face
Grounding
Face
Metal Mounting
Plate
Shielded
Cable
IM
Inverter
Motor cable: 20 m max.
