250
Installation and Wiring of Inverter and Noise Filter
(Model: CIMR-V7B0P1 to B4P0)
LNPE
Single-phase Noise Filter
IM
RS
LN
UVW
E
Control Panel
Metal Mounting
Plate
Grounding
Face
Grounding
Face
Shielded
Cable
Inverter
Motor cable: 20 m max
.
