Omron ZEN Communications Manual

SECTION 3 Communications Data
40
Com Data
◆ Variable Type C6
◆ Variable Type C7
◆ Variable Type C8
◆ Variable Type C9
◆ Variable Type CA
◆ Variable Type CB
Address Data name Data range Remarks Page
0000 Calendar
timer SV
H'01010101 to H'12311231 (-) Calendar timer number specified by
leftmost 2 digits of address.
Leftmost 4 Bytes: Start Month/Day
January 01 to December 31
Rightmost 4 Bytes: End Month/Day
January 01 to December 31
P. 1 8
P. 2 5
Address Data name Data range Remarks Page
0000 Analog com-
parator con-
stant
H'00000000 to H'00000069 (V) Analog comparator number speci-
fied by leftmost 2 digits of address.
00.0 to 10.5 V
P. 1 9
Address Data name Data range Remarks Page
0000 Comparator
constant
H'00000000 to H'0000270F (-) Comparator number specified by
leftmost 2 digits of address.
T/#: 00.00 to 99.99
C: 0000 to 9999
P. 1 9
Address Data name Data range Remarks Page
0000 8-digit com-
parator con-
stant
H'00000000 to H'05F5E0FF (-) Comparator number specified by
leftmost 2 digits of address. (8-digit
comparator)
99999999 max.
P. 1 9
Address Data name Data range Remarks Page
0000 Work bit sta-
tus
H'00000000 to H'00000001 (-) Specify the bit position when read-
ing or writing bit status.
P. 2 0
P. 2 6
Address Data name Data range Remarks Page
0000 HR bit status H'00000000 to H'00000001 (-) Specify the bit position when read-
ing or writing bit status.
P. 2 0
P. 2 6
