Omron ZEN Communications Manual

3.1 Variable Area (Data Range) List
39
Com Data
◆ Variable Type C2
◆ Variable Type C3
◆ Variable Type C4
◆ Variable Type C5
Address Data name Data range (unit) Remarks Page
0000 Holding time SV H'00000001 to H'0000270F (S)
H'00000001 to H'000026E7 (M:S)
H'00000001 to H'000026E7 (H:M)
Timer number specified by left-
most 2 digits of address.
00.01 to 99.99 s
00 min 01 s to 99 min 59 s
00 h 01 min to 99 h 59 min
P. 1 8
Address Data name Data range (unit) Remarks Page
0000 Counter SV H'00000001 to H'0000270F (-) Counter number specified by
leftmost 2 digits of address
9999 max.
P. 1 8
P. 2 2
Address Data name Data range (unit) Remarks Page
0000 8-digit counter SV H'00000001 to H'05F5E0FF (-) 99999999 max. P.18
P. 2 2
Address Data name Data range Remarks Page
0000 Weekly timer SV Normal or Multiple-day Operation
H’000000000000 to
H’006723592359
Pulse Operation
H’000000000000 to
H’006723599959
Timer number specified by left-
most 2 digits of address.
Left 12 bytes are used in the
command.
Leftmost 4 Bytes: Start/End
Day
0: Sunday, 1: Monday, 2: Tues-
day, 3: Wednesday, 4: Thurs-
day, 5: Friday, 6: Saturday,
7: No designation
Middle 4 Bytes: Start Time
00 h 00 min to 23 h 59 min
Rightmost 4 Bytes: End Time
00 h 00 min to 23 h 59 min
Rightmost 4 Bytes: Output
Time
00 min 00 s to 99 min 59 s
00 h 01 min to 99 h 59 min
P. 1 8
P. 2 3

Omron ZEN Specifications

General

Display	LCD
Mounting Type	DIN Rail
Operating Temperature	-10 to 55°C
Power Supply Voltage	100-240V AC
Output Type	Relay, Transistor
Number of Outputs	4-8
Programming Language	Ladder Logic
