2. Target product
2.1. Target product
Confocal Fiber Type displacement sensor
Name Model Version
ZW Controller for Displacement Sensor ZW-CE10
ZW-CE10T
ZW-CE15
ZW-CE15T
ZW Sensor Head for Fiber Coaxial
displacement sensor
ZW-S07
ZW-S20
ZW-S30
ZW-S40
Cable
Name Model Version
EtherCAT Communication cable *1
(RJ45/RJ45)
XS6W-6LSZH8SS□□□CM-Y
XS5W-T421-□MD-K
EtherCAT Communication cable *1
(M12/RJ45, M12 L/RJ45)
XS5W-T421-□MC-K
XS5W-T422-□MC-K
*1：EtherCAT Communication cable specification
• Ethernet twisted-pair cable：STP of CAT5 or more.
• Wiring is straight.
• The shielded is a double cover of the aluminum tape and the braid.
• The shielded of the cable is connected with the shielded of both ends and the connector. (both
ends grounding)
Moreover, please use the cable length between TwinCAT and ZW, between ZW and ZW within
100m.
