OMS LINEA ESSE S.T.01/3S ED.0 REV.14 03/2017
66
8. Finally, connect the foot control to the transformer, make sure, blue connector is with the wires
downwards.
9. If the lamp is to be connected to the dental unit, the lamp stem must be fixed in the relative housing.
The two fixing screws are already in the spittoon unit.
Note:
Refer to the wiring and installation diagrams provided for all electrical connections.
